Home :: Lenovo Power Supply :: Lenovo AP15PC58 Power Supply

Brand new Lenovo AP15PC58 220w Power Supply

For Lenovo hk280-62gp API5PC61 HK360-62GP API5PC58 power supply, enjoys 3 Months Warranty,30-Day Money Back!

Lenovo AP15PC58 Power Supply

Brand new Lenovo hk280-62gp API5PC61 HK360-62GP 220W DPS-220DB-1 C Power Supply.All power supplies are tested by our in house technicians and they are guaranteed to function properly.

  • FRU : AP15PC58
  • Brand:For Lenovo
  • Compatible Model: HK280-62GP,FSP180-50SLV,TFX-180A
  • Wattage: 220 WATT
  • Condition:
    Brand new, Tested, Working Good
Our Price : AU$
  • Qty:
$ QTY:2-5
$ QTY:6-10
$ QTY:11+
  • Availability: In stock
  • Condition: Brand new, Tested, Working Good
  • Warranty: 3 Months Warranty | 30-Day Money Back
  • Compatible Brand:For Lenovo
  • Certification:CE FCC ROHS

Product Details

Please make sure that you are ordering the correct power supply. All of the compatible models listed below come in different sizes and each size has a different power supply. Please check the part #'s, pictures and specifications carefully to make sure that you are ordering the correct power supply.
For FSP Model: AP15PC58
Rated power: 220W
Gross weight: 1.5KG
Whether to support multiple 12V: Not supported
Number of D-type interfaces: 2
Number of SATA ports: 2
CPU power supply interface: 4pin
Power supply type: Non-module
Applicable object: Desktop
Whether to support modularity: Not supported
PFC type: Passive
Graphics power supply port: No graphics power supply port

Part No. HK280-62GP,FSP180-50SLV,TFX-180A,AP15PC58

Compatible For lENOVO Desktop:
FSP180-50SLV FSP260-60SLV


HOW TO REPLACE YOUR PC POWER SUPPLY.

1.Remove the dead pc power supply Once you've disconnected all the leads, look at the rear of the case and find the three or four screws holding the power supply in place. Remove them, then gently lift out the PS, making sure that the cabling doesn't get tangled on, say, a RAM module or expansion card and accidentally pull it loose.

2. Install the new LENOVO AP15PC58 Pc power supply Out with the old, in with the new. Make sure the replacement Pc power supply is set to the correct voltage. Once the old PS is out, put the new one in its place and screw it in. Now just reverse the steps you performed: connect the leads to their respective outlets, replace any extracted components, and consult your photos to make sure you've left no lead unplugged. (You'd be surprised how easy it is to forget, say, the DVD lead, especially when you've spent 10 minutes trying to wedge in that pesky front-panel lead.)

3. Fire it up Before you close up the case, make sure everything works. Connect the power cord to the Pc power supply, plug in your monitor and keyboard, and fire up the machine. Unless you've failed to connect the main leads to the motherboard, it should come right to life, just like before. Let it boot completely, then check to make sure there's power to the optical drive(s) and, if applicable, the front panel.
