Home :: HP Power Supply :: HP D10-240P1A Power Supply

Brand new HP D10-240P1A 240W Power Supply For HP Elite 8000, 8100, 8200 SFF, Pro 6000 SFF

HP 611481-001 611482-001 613762-001 D10-240P1A 240W SFF Power Supply 508152-001 , enjoys 6 Months Warranty,30-Day Money Back!

HP D10-240P1A Power Supply

Brand new D10-240P1A 240W Power Supply For HP Elite 8000, 8100, 8200 SFF, Pro 6000 SFF.

  • HP Spare: 613762-001
  • Model: D10-240P1A
  • HP P/N: 611481-001
  • Wattage: 240W
  • Condition:
    Brand new, Tested, Working Good
Our Price : AU$
  • Qty:
$ QTY:2-5
$ QTY:6-10
$ QTY:11+
  • Availability: In stock
  • Condition: Brand new, Tested, Working Good
  • Warranty: 6 Months Warranty | 30-Day Money Back
  • Compatible Brand:For HP
  • Certification:CE FCC ROHS

Product Details

Please make sure that you are ordering the correct power supply. All of the compatible models listed below come in different sizes and each size has a different power supply. Please check the part #'s, pictures and specifications carefully to make sure that you are ordering the correct power supply.
240W Power Supply for HP Elite 8000, 8100, 8200 SFF, Pro 6000 SFF test

Input: 100-240V ~/4A, 50-60Hz
Output: 240W

Connectors
(1) 6-Pin / 5 Cable Connector
(1) 4 Pin ATX +12V Power Connector
(1) 6-Pin Auxiliary PCI-E Power

Replaceability with the following models:
HP-D2402A0,613762-001,611481-001, HP-D2402E0, CFH0240WWB, D10-240P1A, DPS-240TB A, PS-4241-9HF, PS-4241-9HA, PS-4241-9HB, PC8027

Compatible Models:
HP Compaq Pro 6000 SFF
HP Compaq Pro 6005 SFF
HP Compaq Pro 6200 SFF
HP Elite 8000 SFF
HP Elite 8100 SFF
HP Elite 8200 SFF
Compaq Elite 8300 CMT
rp5800 POS System
rp581 POS System
rp5810 POS System
rp78 POS System



HOW TO REPLACE YOUR PC POWER SUPPLY.

1.Remove the dead pc power supply Once you've disconnected all the leads, look at the rear of the case and find the three or four screws holding the power supply in place. Remove them, then gently lift out the PS, making sure that the cabling doesn't get tangled on, say, a RAM module or expansion card and accidentally pull it loose.

2. Install the new hp D10-240P1A Pc power supply Out with the old, in with the new. Make sure the replacement Pc power supply is set to the correct voltage. Once the old PS is out, put the new one in its place and screw it in. Now just reverse the steps you performed: connect the leads to their respective outlets, replace any extracted components, and consult your photos to make sure you've left no lead unplugged. (You'd be surprised how easy it is to forget, say, the DVD lead, especially when you've spent 10 minutes trying to wedge in that pesky front-panel lead.)

3. Fire it up Before you close up the case, make sure everything works. Connect the power cord to the Pc power supply, plug in your monitor and keyboard, and fire up the machine. Unless you've failed to connect the main leads to the motherboard, it should come right to life, just like before. Let it boot completely, then check to make sure there's power to the optical drive(s) and, if applicable, the front panel.
